Moldbase/Mold components
Products Details :
Mould Base : Standard/Customized
3D Drawing Format : X-T,STP,PRT are available
Typical Grade :
| Carbon Steel |
1045,1050 |
| Tool Steel |
1.2311, 1.2312,1.2344,1.2738 |
| Stainless Steel |
201,304,420 Series |
Tolerance:
|
Top Plate |
A/B Plate |
Stripper Plate |
Bottom Plate |
Ejector Plate |
Spacer Block |
| Thickness |
+0.25/+0.1 |
+0.4/+0.1 |
| Width |
+0.2/0 |
+0.15/-0.15 |
+0.5/0 |
+0.5/-1.5 |
| Length |
+0.2/1 |
+0.15/-0.15 |
0/-0.2 |
| Perpendicularity |
0.05/300 |
Datum Corner 0.01/100 |
0.05/300 |
0.1/300 |
| Other Corner 0.05/300 |
| Parallelism |
0.01/100 |
| Chamfer |
C1.5~C2.0(Reference) |
| C2.0~C3.0(Reference) |
